Product Details
- Size: 7350*2460*3160mm
- Place of Origin: Shandong
- Brand Name: LIXING
- Model Number: JC915
- Weight: 9800.000 kg
| Main Specifications | |||
| Rated load | 1500-2000KG | Maximum tractive force | 20KN |
| Rated bucket capacity | 0.7m3 | Maximum grade ability | 28° |
| Overall weight | 3500KG | Maximum dump height | 3100mm |
| Breakout force | 36KN | Maximum dump reach | 1160mm |
| Whole Dimension | 7350*2460*3160mm | Minimum turning radius | 5500mm |
| Engine | |||
| Model | Xinchai A498BT1 | Rated power | 37kw-2200rpm |
| Transmission | |||
| Torque converter | ZL10 YJ240 | Maximum speed | 16km/h |
| Gear shift | 2forward shift,2reverse shift | Gearbox mode | power shift |
| Axles | |||
| Main reducing spiral bevel gear grade 1 reduction | |||
| Decelerating mode planetary reduction grade 1 | |||
| Minimum ground clearance: 260mm | |||
| Wheel base | 2100mm | Wheel tread | 1500mm |
| Brake system | |||
| Service brake air over hydraulic disc brake on 4 wheels,Parking brake hand brake | |||
| Hydraulic system | |||
| System working pressure | 16mpa | Boom lifting time | 3.3s |
| Total time | 9s | Fuel tank capacity | 45L |
| Function of leveling automatically: yes | |||
| Tire | |||
| Type specification | 14-17.5 | Front /Reartyre pressure | 3/2.2Mpa |
| Cabine | |||
| An ergonomically designed sound proof cabine, enabling wide operational view | |||
- Size: 7350*2460*3160mm
- Place of Origin: Shandong
- Brand Name: LIXING
- Model Number: JC915
- Weight: 9800.000 kg
