Product Details
- Size: 5870*2020*2830mm
- Place of Origin: Shandong
- Brand Name: LIXING
- Model Number: ZL20F
- Weight: 5700.000 kg
| Main Specifications | |||
| Rated load | 2000KG | Maximum tractive force | 50KN |
| Rated bucket capacity | 1.0m³ | Maximum grade ability | 30° |
| Overall weight | 5700KG | Maximum dump height | 2800mm |
| Breakout force | ≥ 60KN | Maximum dump reach | 1050mm |
| Whole Dimension | 5870*2020*2830mm | Minimum turning radius | 5070mm |
| Engine | |||
| Model | Yituo LR4B3-24 | Rated power | 60kw-2400rpm |
| Transmission | |||
| Torque converter | ZL15 YJ280 | Maximum speed | 24km/h |
| Gear shift | 2forward shift,2reverse shift | Gearbox mode | power shift |
| Axles | |||
| Main reducing spiral bevel gear grade 1 reduction | |||
| Decelerating mode planetary reduction grade 1 | |||
| Minimum ground clearance: 250mm | |||
| Wheel base | 2335mm | Wheel tread | 1500mm |
| Brake system | |||
| Service brake air over hydraulic disc brake on 4 wheels | |||
| Parking brake manual king- king- hub brake | |||
| Hydraulic system | |||
| System working pressure | 16mpa | Boom lifting time | 4.7s |
| Total time | 10s | Fuel tank capacity | 80L |
| Function of leveling automatically: yes | |||
| Tire | |||
| Type specification | 16/70-20 | Front /Reartyre pressure | 3/2.2Mpa |
| Cabine | |||
| An ergonomically designed sound proof cabine, enabling wide operational view | |||
- Size: 5870*2020*2830mm
- Place of Origin: Shandong
- Brand Name: LIXING
- Model Number: ZL20F
- Weight: 5700.000 kg
